The key thing here is that the original RIP version is, and has always been, active. A sample of a policy modification that alters the metric type is provided, along with the results observed back at Ale.

These changes are then rolled back to restore the initial behavior:. With the OSPF overlay working on the Juniper Networks portion of the network, we place the equivalent configuration into effect at the Cisco boxes. The commands entered on Malt are shown. Similar commands are also entered on Barley. The resultant OSPF portion of the configuration is shown next, along with the new route map. You must use the default-information originate command instead.

The show ip ospf neighbor command confirms the expected adjacencies to both Barley and Ale. We next display a simulated customer route to confirm that the RIP copy is still being used at the Cisco boxes:.

The output confirms that the RIP version of the route is still active. The LSDB is inspected to make this determination:. The external in fixed code argument to the show ip ospf database command filters the output such that only AS LSAs sent by Lager are shown.

The actual transition normally occurs in two phases. First, make the OSPF routes active, and then, after you confirm proper operation, remove all traces of the legacy protocol and reset the new protocol to its default preference values.

Either way, if something blows up, you can roll back or simply remove the OSPF configuration, and return to RIP operation while determining what went wrong. In both cases, the change will make RIP a less-preferred protocol. The changes are shown for the Juniper router Ale.

Similar commands are also executed at Lager :. Back at the Juniper side of things, you should make a similar determination as to which set of routes is preferred. Here, Ale has installed the default generated by Barley tag , with the RIP version learned directly from Malt also listed tag This is not an issue, as the related subnet Things begin first at the Juniper Networks boxes:.

Though not shown, the related RIP policy and route maps can now be safely removed. You may assume that interface parameters are correctly set. All five of these logical interfaces have been placed into OSPF area 1, which has been set as a stub area. Note that to inject a default route into the stub, you must specify a default metric. The show ospf neighbor command confirms that the adjacency to Ale is established:. With this change, a totally stubby area is born:.

Area 1 is now quite optimized, but it has been called to your attention that the five Note that these summaries are in backbone area 0. The area-range statement replaces individual network summaries that fall within the configured range with a single network summary representing the entire range. There are multiple IP addresses configured on an interface. The goal is to advertise only one or more of those subnets via OSPF and not the other. This article will describe a method on how to advertise selective addresses from the same interface via OSPF.

If one interface is configured under "protocol ospf area" stanza, then both IP addresses are advertised, which is not the requirement. If the lo0 interface is defined under OSPF at the Branch location, then all the IP addresses will be advertised, and we cannot do that.

Here is an example of what should NOT be done;. Notice at the HQ site that all three IP addresses defined on the lo0 are being advertised. Delete the interface lo0 configuration from the ospf. This will stop all three ip addresses from being advertised. Notice that the " default " term is " reject ". So only the IP addresses matching the " from " criteria will be accepted.

Branch1 show protocols ospf display set set protocols ospf export export-ospf set protocols ospf area 0. You might just need to refresh it. Skip to Main Content. Home Knowledge Quick Links.
